3D Gyro Pixel Light WS2812 RGB Matrix Stage Light 500x500mm Modular 1-3 Layers Beam Pixel Dual Source
* Garantie: Innerhalb 2 Jahr.[ Kostenlos zu reparieren, Stellen Sie jegliches Zubehör zur Verfügung,bei Bedarf zurück zur Fabrik,Buyer need pay for the shipping cost.
Product Technical Parameters:
Modell: SDIP-220V-249D-WS2812
Art: 3D Gyro Pixel Light / LED Matrix Panel
Spannung: AC 110-220V
Macht: 48W (1 layer) / 73W (2 layers) / 98W (3 layers)
Größe: 500 x 500 x 98 Mm (1 layer) / 500 x 500 x 138 Mm (2 layers) / 500 x 500 x 178 Mm (3 layers)
LED: WS2812 5050 RGB
IC Model: WS2812
Kanal: GRB
Pixels: 184 (1 layer) / 216 (2 layers) / 248 (3 layers)
Greyscale: 256 levels
Material: PC + BAUCHMUSKELN + metal
Steuerung: TTL / SPI; Kunst-Netz, DMX512, MADRIX, DVI (DVI)
Wasserdicht: Schutzart IP33
Gewicht: 4.25 Kg (1 layer) / 4.95 Kg (2 layers) / 5.70 Kg (3 layers)
Lebensdauer: 50,000 Stunden
Installation: wall screws or ceiling hooks, 4 fixing points per panel
Hauptmerkmale:
1. DUAL LIGHT SOURCE – Each gyro head pairs an addressable WS2812 pixel ring with a central RGB beam lens, so pixel graphics and beam effects run from one fixture.
2. MODULAR 1/2/3 LAYERS – The same 500 x 500 mm panel stacks into two or three layers in 40 mm steps, building taller 3D pixel walls without changing the fixture.
3. TOOL-FREE ROTARY LOCK – Heads seat into the socket and lock with a twist; four heads per panel, fast to install and service on site.
4. DAISY-CHAIN POWER AND SIGNAL – AC 110-220V hand-in-hand power plus RJ45 in/out per panel; TTL/SPI at the fixture, Kunst-Netz / DMX512 / MADRIX from the controller.
5. 184-248 PIXELS PER PANEL – WS2812 5050 RGB, GRB channel, 256 grey levels, 50,000-hour lifespan, PC + BAUCHMUSKELN + metal housing, Schutzart IP33.
Applications: nightclub, live stage, touring production, exhibition, TV studio, architectural feature wall
