72 Pixel Train Bar WS2811 RGB Addressable LED Pixel Bar Light

* 保証: 以内 2 年。[ 修理無料, アクセサリを提供する,必要に応じて工場に戻る,購入者は送料を支払う必要があります。]

Product Technical Parameters:

• Working Voltage: DC 24V
• 消費電力: 75W
• 導かれた源: RGB 3-in-1 addressable pixels
• Pixel Quantity: 72 ピクセル (1.35m length)
• Driver IC: WS2811
• Channel Order: GRB
• Grey Scale: 256 levels
• Control Protocol: SPI / TTL
• 制御モード: External pixel controller (signal-in / signal-out daisy chain)
• Housing Material: ABS + PC
• IPレーティング: IP33 (splash resistant)
• Overall Size: 1345 x 117.5 x 113.5 ミリメートル
• 正味重量: 3.13 キログラム
• Mounting: Wall or rail mount via base studs

Key Features:

• 72 independent addressable pixels run a chase, wave, or slow colour fade along the full 1.35 m barrel.
• RGB 3-in-1 colour mixing inside the fixture — no gel filters needed.
• Segmented glossy ring dividers split the barrel so light escapes as separate glowing arcs, like train carriages.
• Headlamp projector lens in the end cap throws a fan beam onto the ceiling.
• Driven by an external SPI/TTL pixel controller; fixtures link signal-in / signal-out for long runs.
• Semi-cylindrical ABS+PC housing with screw-fixed end cap and mounting studs.

ティッカー / Channel Description:

• Pixel control via external SPI/TTL pixel controller (WS2811 protocol, GRB order, 256 grey levels).
• Each of the 72 pixels is individually addressable for chase, wave, jump, fade and custom mapping effects.
• Fixture links signal-in / signal-out so multiple Train Bars can be chained to one controller.

Applications:

• Bars, lounges and pubs
• KTV rooms and private clubs
• Live stages and performances
• Rental and event production
• Showrooms and commercial feature walls
